Mappable functions via the Toggle Switch Action menu.

Press > 0.5 s during playback to enter audio scrub mode.

Press Menu and HP knob to enter Take List.

Press to open headphone preset menu and select.

Press with Channel Select switches 1-6 for shortcuts to Menu Favorites 1-6. The Menu button will flash red to indicate clipping on the headphones.

Continuous yellow = unit is off and both L-mount batteries are fully charged.

Flashing yellow = unit is off and charging L-mount batteries.

Flashing blue = power is off and holding timecode.

Power condition: green = good, yellow = warning, red = shutdown imminent.

The audio may be heard in scrub mode up to 2x speed. Then rotate clockwise for fast forward or counter-clockwise for rewind speeds of 0x, 1/8x, 1/4x, 1/2x, 1x, 2x, 4x, 8x, and 16x. While playing or paused, press the headphone knob >0.5 s to enter Scrub mode. Push right while holding Select to add a Q-mark. When the 833 is playing back or paused, moving the joystick to the left (>) fast forwards at 2x speed, then after holding for 5 seconds, it increases to 16x speed. While in playback, push and hold left to rewind. While in standby, push left to load the previous take. The LED ring as well as the active file in the display will flash to indicate that Pause is active. While in playback, push down again to pause playback.

Push down on the Transport control to begin playback of the last file recorded or file currently loaded. While in standby, press and hold to display next take name. Press in the Transport control to stop recording or playback. The LED ring illuminates red while recording is underway. Push up the Transport control to begin recording a new file. The ring LED will flash orange indicating post roll while writing to media. Push and Push HP knob to access Receiver Overview screen if a SuperSlot accessory is connected.Ī joystick (with its illuminated LED ring) on the front panel is used to perform various transport control functions. Push and rotate HP knob to zoom meter scale. Push with channel Select switched 1-6 for shortcut to Meters Preset 1-6. Push to view and select various metering presets. Use Toggle Switch Actions to set the Select and /or HP knobs as faders for Ch 7,8. Channel 7-8 faders are accessible via the Channels 7-8 menu or using */** + PFL switch shortcuts. Use Toggle Switch Actions to set the Select and /or HP knobs as PFLs for Ch 9,10.Ĭontrols the audio level of the channel as it contributes to the L/R mix and any destinations selected in routing as “Post”. Channel 9-10 PFLs are accessible via the Channels 9-10 menu or using */** + PFL switch shortcuts. Also used for accessing virtual keyboard for channel naming and various shortcuts. Pre/Post Fade Listen selects the channel in the headphones for Pre/Post Fade Listen while simultaneously entering the channel screen. Provides visual indication of channel signal condition, solo and mute, and whether a channel is on or off. Use Toggle Switch Actions to set the Select and /or HP knobs as trims for Ch 7,8. Channel 7-8 trims are accessible via the Channels 7-8 menu or using */** + PFL switch shortcuts. To conserve power, turn off unused channels by rotating channel trim fully counter-clockwise.

Turns the channel on/off and sets the input gain for the channel. Our friendly and knowledgeable support team, based in the USA and the UK, is here for all your questions and comments. Optional +4 Plugin adds four fully-featured channels.Optional NoiseAssist and CEDAR sdnx noise suppression plugins.Dugan Automixing/MixAssist for up to 8 channels.USB-A and C ports for SD-Remote app, linear fader control via MCU, keyboard, and file transfer.6 ultra low-noise, 8-Series microphone preamplifiers.A tactile interface with dedicated faders, trim knobs, and PFL switches makes this mixer-recorder ideal for run-and-gun bag use. Like the popular Sound Devices 633, the 833 is small, lightweight, and compact. The 833 is the professional’s tool for mobile and small productions. X-KEYS® PROGRAMMABLE KEYPADS, STICKS & KEYBOARDS 91
